In order to understand the sound qualities and atmosphere of various locations within my proposed site, I have taken a number of sound recordings as documented below.
On the above annotated site plan I have highlighted the noisiest areas of the site (red), this happens to be along the more exposed eastern region of the site and is perhaps due to the open nature and the large car park to the south offering no protection to the wind.
Surprisingly, the central tomb in the ruin was louder than expected along with the southern access point and along side the church (orange). These areas where I expected them to be more peaceful were actually louder, perhaps due to the surrounding architecture which causes sound to reverberate/become amplified.
The most quiet/peaceful areas of the site were the northern entrance and around the westerly edge of the ruin. This is a much more sheltered area of the site due to the adjacent buildings, trees, topography and ruin itself.
Overall the sound recordings feature a lot of birdsong, which is evident in most clips. Pedestrian and some light vehicular traffic can be heard in places. Where the recordings are in an open area, the main sound is that of a strong wind which gives a sense of the environmental qualities on the day of recording.
I have learnt from this activity that the site currently offers many ‘sound environments’ – from open and breezy to sheltered and calm. There is a lot of birdsong which highlights the site’s ecological/habitat importance. There is little sound of traffic which was surprising meaning overall the site is relatively quiet given its urban context.
Are you new to blogging, and do you want step-by-step guidance on how to publish and grow your blog? Learn more about our new Blogging for Beginners course and get 50% off through December 10th.
WordPress.com is excited to announce our newest offering: a course just for beginning bloggers where you’ll learn everything you need to know about blogging from the most trusted experts in the industry. We have helped millions of blogs get up and running, we know what works, and we want you to to know everything we know. This course provides all the fundamental skills and inspiration you need to get your blog started, an interactive community forum, and content updated annually.
Through my investigative report I have started looking at examples of responsive facades in contemporary architecture. A responsive facade is one that alters to a given stimulus. The facade usually responds in order to control the internal climate of the building, although could be for aesthetic purposes too. It would be more beneficial to have some effect on the building rather than appearance so that the extra cost and material is justified. The stimulus could be daylight levels, internal/external temperature or even time of day. A good precedent for responsive facades is the Al Bahar Towers in Abu Dhabi by Aedas.
Inspired by a mashrabiya (a traditional Islamic lattice shading device), the shading system on this pair of towers was developed using parametric design for the geometry of the moving triangular facade panels which open and close in response to sun exposure and the changing incidence angle of the sun throughout the year.
The screen operates as a curtain wall, sitting two meters outside the buildings’ exterior on an independent frame. Each triangle is coated with fibreglass and programmed to respond to the movement of the sun as a way to reduce solar gain and glare. In the evening, all the screens close.
The building responds to the external stimulus of UV light: as the sun rises, the shading components along the east side of the building remain closed, while open on the remainder of the building. As the sun moves around the building throughout the day, the dynamic facade responds with components opening/closing accordingly in order to shade the glazing.
To better understand the mechanism and how the facade components work I decided to model them:
This simple folding mechanism is very effective in shading the glazed building, this is particular important due to the hot climate where the buildings are located. This modelling exercise got me exploring other folding techniques to see how else this shading device could have been designed.
As you can see I experimented with three forms and folding techniques and these could all be developed to a solar shading device, I developed the first example into a design proposal below.
If attached to central support with an electronically programmed mechanism that could slide to open/close the component the surface area would open up to provide the shading. This design could be scaled-up to shade whole facades of buildings. It would offer more thermal shading if installed on the exterior of a building (outside glazing) however it could be fitted behind a glazed rainscreen, though thermal gain would still be an issue to some extent.
Having come to grips with 3D modelling program Rhinoceros over the bank holiday weekend, I have started to practice using the script writing plug-in Grasshopper. This uses script to help generate 3D forms, within which, parameters can be changed which affects the generated form. Below are three parametric towers, modelled through Grasshopper into Rhinoceros. I have altered the parameters in the script and the differences between the three include height, rotations and distance between ‘floors’:
Although a quick form-generating exercise, it is clear that this method could offer unexpected design solutions that could inform future projects.
As mentioned in my previous post, my outline concept of investigation steered me towards parametric design. I have been doing some insightful reading around this subject for the report, including a very good book suggested by my tutor called Algorithms Aided Design by Arturo Tedeschi.
The book explains parametric design strategies using Grasshopper for Rhinoceros and I am looking forward to developing my skillset in this area over the coming weeks…
From the initial outline concept of Crystals, further research in this area has led me to discover and learn more about the atomic structure of crystals in general. Crystals are composed of ‘perfect’ structures known as Lattices. Structural diagrams of the atoms could be likened to architectural structural diagrams.
What has been very eye-opening for me is what happens when the atoms do not appear in their ordered position; the structure of the crystal responds and defects/impurities become evident within the matter. Within the physical build-up of the matter there can be either missing or additional atoms; in each case the structure changes. The atoms have a ‘field of influence’ – and when a parameter changes, the matter responds accordingly.
My investigations have led to me to another area of architectural research that I am really excited to investigate further: Parametric Design.
As part of my early investigative work around the concept of crystals, I initially explored the notion of buildings being informed literally by crystals. One building I found was the NYC Salt Store in Manhattan, the form of which was derived from that of a salt crystal. My drawing of the building below:
Although I appreciated the unique form of the building and its relationship to its function of storing salt, I felt the connection to my initial area of research was too literal and I decided not to focus on crystals informing the form/appearance of buildings and intend to develop my research in another area that would offer more of a challenge and open my research into another area of study.
The starting point for my investigative report is going to based around the concept of Crystals. I have selected this area of research as Crystallography interests and intrigues me: there is a mythical, magical and enchanting quality to crystals and I feel that research into this area may provide theory concepts that could be linked to architectural practice.
As an initial starting point, I believe there could be multiple potential paths. After studying the Turner Contemporary and its ‘crystalline’ appearance I could chose to focus on the aesthetic link between crystals and architecture. Or as I develop my research into this area I could be taken down a different route. I am excited for what I might discover…
There is a plethora of materials on site, including ancient and more recent masonry. The masonry tells many stories: in places it is reused from the nearby Roman Wall, some of the masonry to the priory would have originally been coated in plaster and some of it is in-fill repair work. The newer masonry is on the adjacent Church of St. Botolph. The many layers of technique and history remind us of the passage of time that the site has witnessed.
There is a clear contrast between the brick sizes, the narrow red brick is typically Roman (likely reused from somewhere in town), there are rough flint stones and newer London stock brick. The range in colours is also interesting as it denotes material and period. Some brickwork had been defaced; I even spotted a brick with ‘JAKE’ carved into it – not me I promise!
Following a few visits to my selected site for D4 (St. Botolph’s Priory, Colchester) I have made some sketch-studies of the ruinous building. The ruins fascinate me; although you can’t see the building in its former state, you can use your imagination to see what would have been: windows, doorways, high-level walkways.
It is important for me to understand and appreciate the existing so that I can use this to inform my proposal on site.
With the intention of exploring the concepts of ‘time’ and ‘place’ through architecture in this academic year, the site was crucial in ensuring that I can develop a scheme that responds to this theme. I have chosen the grounds of St. Botolph’s Priory in Colchester, highlighted in green below and located south of the ancient walled Roman city.
I have carried out initial site documentation and research, the next step is to develop my project brief and define the user group for a more focused approach to the project.
